Trapezoidal Tin Metal Roof Mounting System with Short Rail

With the short rail for trapezoidal tin roof mounting system, PV module will assemble quickly and safely. Each of short rail bracket including 4 self-drilling screws with sealing washer.

  • Item Name :

    Tin Metal Roof Mounting System
  • Standard :

    AS/NZS 1170, JISC8955-2017
  • Application :

    Metal Roof
  • Material :

    Aluminum+Stainless Steeel
  • Warranty :

    12 years
  • Custom :

    Customized
  • Lead Time :

    15-20 days
  • Sample :

    Available

Customized Trapezoidal Metal Roofing Mounting Bracket System

The mini rail bridge is a kind of trapezoidal tin roof bracket for solar panel module installation and other applications on metal roofs. With only a few components, this metal roofing mounting system could get a material saving and economical solution on the photovoltaic project. Also the EPDM cushion is applied on the mounting rail against the roof, which creates a separation layer between the different materials.



Feature

A. Design for trapezoidal sheet roof

B. Wind and snow load capacity

C. Exceptional resistance to corrosion

D. Shorten on-site installation time

Metal Roof Mounting Systems

                          About It


Short rail for mounting solar modules on trapezoidal sheet metal roofs, including 4 thread-forming tapping screw with sealing washer.  All components are made of aluminum and stainless steel. A 12-year guarantee on the tin roof mounting systems


Q1: Do I have to pay for the sample?

Cowell Solar Mounting: Well, the free sample is offered if they have on stock. The customized product have to be charged, but the sample cost could return when mass production.
Q2: Does it matter that I do not have experience to install?
Cowell Solar Mounting: Pls do not worry, most of accessories are designed to be highly pre-assembled. And we provide includes the structural analysis as well as the installation plan for all components.
Q3: What is your guarantees and services?
Cowell Solar Mounting: All of product have strictly quality control on the production line. We guarantees 12 years life time.
Q4: Do you have the factory? And do you offer the custom service?
Cowell Solar Mounting: Yes our factory have established for about 30 years, and we have the professional technicians and engineers to meet your customized requirement.
